Specifications
Everything a drawing set or a purchase approval needs, on one sheet. Print it or save it as a PDF.
Components
| Component | Material | Finish | Rated load | Length | Price excl. GST |
|---|---|---|---|---|---|
| Picture Hanging Rail | Aluminum | White, Black, Silver | 25 kg per metre | Cut to order | ₹250 / ft |
| 150cm Perlon Cord with Cobra | Perlon (Nylon) | Transparent | 20 kg | 150 cm | ₹850 each |
| 250cm Perlon Cord with Cobra | Perlon (Nylon) | Transparent | 20 kg | 250 cm | ₹1,250 each |
| 300cm Perlon Cord with Cobra | Perlon (Nylon) | Transparent | 20 kg | 300 cm | ₹1,450 each |
| 4kg Hook | Steel | — | 4 kg | — | ₹220 each |
| 15kg Zipper Hook | Steel | — | 15 kg | — | ₹450 each |
Ratings are the manufacturer's stated capacities, not independent laboratory certificates. GST is charged at 18%.
Selecting the parts
- Cord length, by ceiling height
- 150 cm up to 9 ft; 250 cm from 9 to 12 ft; 300 cm above 12 ft. When in doubt, take the longer cord: the hook runs to any height along it.
- Cords per artwork
- Two cords per artwork keeps it level and halves the load on each hook. One cord suits small, light frames.
- Hook, by load per hook
- Up to 4 kg per hook: standard hook. Up to 15 kg per hook: Zipper hook, adjusted with one hand.
- Load limit
- The lowest rating in the combination governs: rail 25 kg per metre, cord 20 kg, hook 4 kg or 15 kg. Fixings must suit the wall or ceiling substrate.
- Mounting and supply
- Wall or ceiling mounted. Rail is supplied cut to the piece lengths ordered, in 0.25 ft steps, up to 100 ft a piece.
Specification clause
For drawing notes and bills of quantities. Edit the bracketed choices.
Picture hanging system: JAM by Window Techs aluminium picture rail, [white / black / silver] finish, [wall / ceiling] mounted, supplied cut to length. Transparent Perlon cords with Cobra rail connectors, [150 / 250 / 300] cm, two per artwork. Sliding steel hooks rated 4 kg, and Zipper hooks rated 15 kg for heavy works. Supplied by Window Techs India Private Limited, GSTIN 08AABCW1291M1ZZ.
